Sanding machine technical specification | ||||
No. | Item | Unity | Parameter | Remarks |
1 | Applicable diameter | mm | 196~410 | |
2 | Height of inner tank | mm | 150~1300 | 6.5L~30L |
3 | The mouth diameter of inner tank | mm | 60~72 | |
4 | The distance between double mouth of inner tank | mm | 200~300 | |
4 | Sheet material | Low carbon cold rolled steel plate | SPCC/TC210L/TC300L | |
5 | sheet thickness | mm | 1.5~2.0 | |
6 | Sheet yield strength | MPa | ≤400 | |
7 | station number | pcs | 2 | Double inne_tank |
4 | Single inner_tank | |||
8 | Double inner_tank single shift capacity | pcs | 800 | Double inner_tank single shift 10 hours |
9 | Average production takt | s /pcs | 45 | 60L as standard, including loading and unloading. |
10 | Staffing | pcs | 1-2 person | |
11 | compressed air pressure | MPa | 0.6~0.65 | |
12 | flow | m3/min | 20 | Manufacturer's confirmation |
Main technical parameters and technical requirements：
1、Single inner Tank：Fromφ220,toφ410，product longest length:1250mm
2、Maximum height less than：1400 mm；The maximum inside diameter is less than：φ410 mm；
2、Production capacity: 60 pieces/hour, (typical workpiece 50L single bile)；
3、Studio dimension：Length 3000×Width 1200×Height 2200mm（temporary， according to the design）；
6、Power supply：380V/50Hz；
7、Power：≤28Kw/set（Exclusive air compressor）；
8、Use compressed air to supply air pressure：0.4-0.7Mpa；Flow：40m³/min；
9、derusting grade：Sa2.5 grade (GB8923-88)；
10、Nozzle diameter and quantity: three hole nozzle, 4 pieces/set；
11、Dust emission in line with national environmental standards (≤120mg/m3)；
10、Noise≤75dB；
11、Applicable steel sand type: steel sand;
12、Suitable for steel sand particle size：0.5~1.20mm；
13、Steel sand automatic recovery, sorting, recycling；
14、Sandblasting operation mode: manual operation + manual sand cleaning；
15、Operator: 1-2 people/set.
